Front Brake Discs Pads Kit For TOYOTA RAV 4 PRIUS PLUS

£77.00

Brand: Mapco
Availability: 2 In Stock
SKU: 47577
Loading delivery info...
* Applies to DPD Zone 1 only

£77.00

-Description-

Brand New MAPCO Brake Disc Set – High Quality Replacement Parts

-Technical details-

Vehicle Type Year Part Numbers Engine output and capacity Engine
TOYOTA PRIUS PLUS (_W4_) 1.8 Hybrid (ZVW40W, ZVW41W)
TOYOTA RAV 4 III (_A3_) 2.0 (ZSA35)
TOYOTA RAV 4 III (_A3_) 2.0 (ZSA35_)
TOYOTA RAV 4 III (_A3_) 2.0 4WD (ACA30_)
TOYOTA RAV 4 III (_A3_) 2.0 4WD (ZSA30)
TOYOTA RAV 4 III (_A3_) 2.0 4WD (ZSA30_)
TOYOTA RAV 4 III (_A3_) 2.2 D (ALA35_)
TOYOTA RAV 4 III (_A3_) 2.2 D 4WD (ALA30_)
TOYOTA RAV 4 III (_A3_) 2.4 (ACA36, ACA38)
TOYOTA RAV 4 III (_A3_) 2.4 4WD (ACA31, ACA33)
TOYOTA RAV 4 IV (_A4_) 2.5 4WD (ASA44)
05/2011 -
03/2009 - 06/2013
12/2008 - 06/2013
02/2006 - 06/2013
03/2009 - 06/2013
12/2008 - 06/2013
12/2008 - 06/2013
12/2008 - 06/2013
11/2005 - 12/2013
11/2005 - 06/2013
12/2012 -
4351242040 LEXUS
04465-42140 TOYOTA
04465-42150 TOYOTA
04465-42170 TOYOTA
04465-42180 TOYOTA
04465-42190 TOYOTA
43512-42040 TOYOTA
4351242040 TOYOTA
4351242080 TOYOTA
100KW (136hp) 1798 ccm
109KW (148hp) 1987 ccm
116KW (158hp) 1987 ccm
112KW (152hp) 1998 ccm
109KW (148hp) 1987 ccm
116KW (158hp) 1987 ccm
110KW (150hp) 2231 ccm
110KW (150hp) 2231 ccm
125KW (170hp) 2362 ccm
125KW (170hp) 2362 ccm
132KW (180hp) 2494 ccm
2ZR-FXE
3ZR-FAE
3ZR-FAE
1AZ-FE
3ZR-FAE
3ZR-FAE
2AD-FHV, 2AD-FTV
2AD-FHV, 2AD-FTV
2AZ-FE
2AZ-FE
2AR-FE

Brake disc technical drawing

A B C
Vehicle position Brake Disc Type Brake System Outer diameter Height Brake Disc Thickness
Front Axle Vented 275 mm 46,2 mm 25 mm
D E F F(x) G
Centering Diameter Bolt Hole Circle ? Bore ? Number of Holes Inner diameter
62 mm 114,3 mm 14,5 mm 5 145 mm
